원래 장소:
치안스, 중국 (본토)
브랜드 이름:
XCMG
인증:
IOS/CE
모델 번호:
GR5505T PRO
| Model: Motor Grader | Condition: Brand New | Application: Construction |
| Brand Name: XCMG | Model Number:GR5505T Pro | Certification: ISO,CE |
| Rated Working Pressure: 25MPa | Max. Gradeability: ≥30% | Dimension: 16430*4560*4810mm |
| Total Weight: 74000kg | Engine: 2806D-E18TA | Place of Origin: Jiangsu, China (Mainland) |
| Warranty: 1 year | Color: Yellow | After-sales Service Provided: Engineers available to service machinery overseas |
| Item | GR5505T PRO | ||
| Basic parameters |
Engine model | 2806D-E18TA | |
| Rated power/speed | 447kW/2100rpm | ||
| Machine dimension(standard) | 16430*4560*4810mm | ||
| Machine weight(standard) | 74000kg | ||
| Tire specification | 29.5R29 | ||
| Ground clearance (Front axle) | 890mm | ||
| Wheel track | 3650mm | ||
| Axle distance between front and rear | 10460mm | ||
| Wheel base between middle and rear | 2240mm | ||
| Performance parameters |
Drive speed, forward | 4.6, 5.9, 8.7, 11.7, 17.7,25.1, 32.2,42.7km/h | |
| Drive speed, reverse | 4.5,8.7,17.2, 32.6km/h | ||
| Traction force f=0.75 | ≥390kN | ||
| Maximum gradeability | ≥30% | ||
| Tire inflation pressure | 500kPa | ||
| Work system pressure | 25MPa | ||
| Transmission box pressure | / | ||
| Working parameters |
Maximum steering angle, front wheel | ±48° | |
| Allowable tilt angle, front wheel | ±18° | ||
| Maximum oscillation, front axle | ±16° | ||
| Maximum oscillation, balance box | Front 20°, rear 20° | ||
| Maximum steering angle, frame | ±25° | ||
| Minimum turning radius | 12.5m | ||
| Blade | Maximum it above ground | 460mm | |
| Maximum cutting depth | 553mm | ||
| Maximum tit angle | 55° | ||
| Cutting angle | 40° | ||
| Swivel angle | 340° | ||
| Length * height | 7300x1025mm | ||
| Capacities | Coolant | 75L | |
| Fuel tank | 1100L | ||
| Engine | 72L | ||
| Transmission box | 120L | ||
| Balance box | 7OL | ||
| Main reducer and wheel reducer | 83L | ||
| Hydraulic oil | 280L | ||
